Avaya ERS 5000 Series Switch

Available Models:

The 5510-24T is suitable for high-performance wiring closet applications or as a horizontally stacked, top-of-rack switch in the data center. This relatively low-density option offers 24 ports of 10/100/1000, including two in a combo configuration with 1000BASE-X SFP uplink ports.

The 5520-24T-PWR is ideally suited to a high-performance, convergence-centric wiring closet role. With 24 ports of 10/100/1000 offering 802.3af Power-over-Ethernet, including four that are in a combo configuration with 1000BASE-X SFP uplink ports, the 5520-24T is a relatively low-density option.

The 5530-24TFD can be used for data center aggregation, or as the core of a small network. With 24 ports of 10/100/1000, including twelve in a combo configuration with 1000BASE-X SFP ports, and two ports of 10GBASE-X XFP connectivity, this switch is a versatile and powerful aggregation platform. As with all 5500 models, it features support for an external redundant power supply and full Stack-compatibility with the 5600 models.

With 48 ports of 10/100/1000, plus two ports of 10GBASE-X XFP connectivity, the 5650TD can be used in a high-performance wiring closet, or as a horizontally stacked, top-of-rack switch in the data center. As with all 5600 models, it features field-replaceable power supplies for enhanced resiliency.

For high-density, high-performance wiring closet functions, the 5698TFD offers 96 ports of 10/100/1000—including six in a combo configuration with 100/1000BASE-X SFP ports and two 10GBASE-X XFP ports. This top-of-the-line switch offers significant advantages in pricing and power consumption. As with all 5600 models, it features field-replaceable power supplies for enhanced resiliency.

This model offers 48 concurrent network interfaces, with 48 ports of 10/100/1000, including two in a combo configuration with 1000BASE-X SFP uplink ports. It can be used as a high-density option in the high-performance wiring closet, or as a horizontally stacked top-of-rack switch in the data center.

This switch is ideally suited as a high-density option in the high-performance, convergence-centric wiring closet. It offers 48 concurrent network interfaces: 48 ports of 10/100/1000 with 802.3af Power-over-Ethernet, including four in a combo configuration with 1000BASE-X SFP uplink ports.

Suitable for data center aggregation or as the core of a small network, the 5632FD offers 32 concurrent network interfaces: 24 ports of 1000BASE-X SFP plus eight ports of 10GBASE-X XFP connectivity. As with all 5600 models, the 5632FD features field-replaceable power supplies for enhanced resiliency and full Stack-compatibility with the 5500 models.

The 5650TD-PWR offers 50 concurrent network interfaces: 48 ports of 10/100/1000 with 802.3af Power-over-Ethernet, plus two ports of 10GBASE-X XFP connectivity. It is ideally suited as a high-density option in the high-performance, convergence-centric wiring closet. As with all 5600 models, it features field-replaceable power supplies for enhanced resiliency.

This switch offers 98 concurrent network interfaces: 96 ports of 10/100/1000 with 802.3af Power-over-Ethernet, including six ports that are in a combo configuration with 1000BASE-X SFP ports, along with two ports of 10GBASE-X XFP connectivity. It is ideally suited as a high-density option for the high-performance, convergence-centric wiring closet. The 5698TFD-PWR provides significant advantage in price and power consumption, and features field-replaceable power supplies for enhanced resiliency.

Ethernet Routing Switch 5000 Series
Designed for enterprise data center, wiring closet and small core applications, this versatile family of stackable Ethernet switches offers high levels of performance and a range of advanced capabilities. Features include an industry-leading resilient stacking capacity, advanced routing, QoS, convergence, and security capabilities. Support for Switch Clustering in small networks is also available.

The Ethernet Routing Switch 5000 Series includes the original 5500 models and the new 5600 models; all are fully Stack-compatible offering both excellent investment protection and a straightforward way to accessing the latest and greatest hardware. This product line features the Industry’s leading resilient Stacking solution—Avaya Stackable Chassis—and can boast to be the only product to pass the Terabit barrier for Stacking capacity.
Features and Benefits
Improve application responsiveness
The 5000 Series features high-performance virtual hot-swap capability with industry-leading capacity to enhance and optimize application responsiveness.

Get the performance you need
This highly versatile family of switches has models to suit a variety of advanced enterprise requirements, including switch cluster, horizontal stacking and aggregation.

Lower your Total Cost of Ownership
By delivering the best price per port for high-performance Gigabit Ethernet, the 5000 Series offers a lower total cost of ownership.
